-30°C Low Temperature Freezer Upright Type DW-30L785

Temperature Control
* Microprocessor control, digital display to 0.1°C resolution temperature is adjustable from -10°C to -30°C.

Ergonomic Design
* Single stage refrigeration technology & design, strong cooling and quick freezing.
* Outer and inner doors, double gaskets and extra thickness of Insulation ensure reliable operation and safety of sample storage.
* Eagle-mouth shaped handle provides strong locking and easy door opening
* Casters wheels with lock, is designed for easy moving

Safety Control
* Power-on delay function, off-cycle protection is to ensure the security of the compressor

Alarm System
* Audible and visual alarm in two alarming methods:
Buzzer alarming and digital flashing alarming
* Alarm conditions included High and Low limit alarm, sensor malfunction alarm, (optional) Power Failure Alarm.

Cooling System
* Fast cooling system is generated by imported compressor and EBM fan motor.
* Strong cooling system is generated by copper tube evaporator and condensing system.

Specifications
Alarm conditions: High & Low alarm, Sensor Error, (optional) Power Failure Alarm
Alarm System: Audible and Visual alarms with battery back-up
Cabinet External: Powder Coated Steel Sheet
Cabinet Internal: Stainless Steel Sheet
Capacity: 785 litres
Casters Wheels: 4pcs
Certificate: ISO13485
Condenser: Fan Cooling Fin Type
Door/Door lock: Double Gasket Formed door/ 1 unit of door lock with key
Evaporator: Copper Coil
Foam Insulation: 120 mm thick CFC-free polyurethane
Inner Door: N/A
Interior dim (mm) WxDxH: 710x790x1400
Model: DW-30L785
Net Weight: 170KG
Overall dim (mm) WxDxH: 860x940x1950
Power Consumption: 9.3kW h/24h
Power Input: 520W
Power Supply:220-240 Vac, 50Hz, Single Phase
Refrigerant: Mixed CFC FREE Refrigerants
Refrigeration System: Direct Cooling
Sensor: NTC
Stainless Steel Shelves: 3 shelves, 4 compartments
Temp. Setting & Display: Digital Display to 0.1°C
Temperature working range: -10°C to -30°C (adjustable)
